Nutrition/Enriched/Instant/Artificial Rice Process Line

Product description

NO.	Name	Brief introduction
1	Raw material	Rice flour, broken rice
2	Basic Recipe	Water ,food grade additives
3	Processing flow	Mixing -Extrusion - Conveying-Drying-Cooling-Packing
4	Equipment	Mixer; Screw elevator; Double screw extruder; Air conveyor;  Dryer with cooler.
5	Final products	Nutrtional rice  Artifical rice  Fortified rice
6	Machine material	Stainless steel 304 or as customer’s request

Product sample





Detailed information

	Name	Automatic multi grains flour handing, dosing,storage, weigh transfer system
	Capacity	200kg/h-1500kg/h,depend on factory space, storage silo,
	Features	1. Used to feeding, storage, transfer,weigh mixing rice flour , ready go to extruder machines  2. Fully automatic, labor cost  3. Fully stainless steel materials 304 made    4. Automatic controlling  5. High precision  6. Dust collection
	Working Principle	Flour transferred by feeding station to storage silo, screw conveyor transfer flour  to the weigher machine per batch, flour transfer to the mixing machine,  under high speed, ready go to extrusion system



	Name	Doule Screw Extruder
	Capacity	200kg/h-1000kg/h depend on food shape
	Usage	Raw material is curing and puffed in extruder, becoming different shapes of puffing snacks with moulds changing.
	Working rinciple	It consists of 1. Feeding system, 2. Extruding system, 3. Cutting system, 4. Heating system; 5. Cooling system 5. Controlling system. Grains flour get extruded,heated under high pressure formed into various by different forming die nozzles, ready for the flaking, drying or toasting

 Core characteristic:

	Name	Multi Layers Hot air circulated  Dryer machine
	Capacity	200kg/h-1500kg/h depend on food, moisture
	Usage	Used for  cereals drying, moisture, extend storage time
	Working Principle	Heating source can be electric, gas, steam and fuel. The material is stainless steel 304. Machine consist of below components: 1. Drying system 2. Heating system  3. Controlling system 4. Moisture discharge system Features: 1. Drying speed adjustable by inverter  2. Drying temperature adjustable  3. Fully Stainless steel 304

European type modularround barrel
Barrel: European modular 4D-round barrel design, equipped with alloy lining, long work life. The temperature of each zone is controlled independently.

Modularscrew:can adapt to different materials and easy to be changed, don’t need to change full piece of screw, only a part of it. Made of hard alloy, strong wear resistant.

Cutter: with lateral movement to allow exchange of the knife head even during production. European technology design, easyoperation and adjustment.
Powerful direct-cutting system with linear slide rail, available to high production.

Frame: International easy cleaning design
User-friendly automation system forefficient and safe production.
PLC control system, touching screw.
The memory storage function of various parameter settings for users to use
The system has alarm processing, alarm data viewing, and shutdown protection functions


Cutomer case



Company profile


Shandong Arrow Machinery Co., Ltd. is a company specializing in R&D, production, sales, application promotion of food engineering projects. As a professional food processing equipment &whole plant engineering problem solvers in China, machines served for more than 970 companies, export to 116 countries, more than 20 years engineering team. We aim to create a great future together with global customers.
* More than 15 years experience
* Professional design,fabrication,installation team
* Professional R&D center

FAQ
Q: What kinds of products can be made?
A: corn flakes, puffs, breakfast cereals food, animal feed, animal feed, soy protein texture food.
Q: What's the delivery time?
A: We usually need 40-45 days for large sizes, depends on the finished product, so machine wash-change.
Q: What about the installation service?
A: Depending on the whole line of equipment price list, it usually takes 2-3 weeks. We will provide you with installation instructions, such as start, as well as their operation machines for quality control, testing of different recipes.
Q: What is the warranty period for using the device?
A: 1 year for auger and cylinder due to modular design, changing the wearing parts will be OK, unlike a full set of screws, no need to change the whole set.
